NEMA 5-15P to PowerCon NAC3FCA Cable
Touring-grade 15A/125V locking power for pro AV
- Connectors: NEMA 5-15P (Standard US Plug) to Neutrik NAC3FCA (Blue)
- Current: 15A continuous / 125V (1875W max)
- Cable: 14AWG SJTOW jacket (weather/abrasion resistant)
- Locking: Twist-lock prevents accidental disconnection
- Use Case: Touring audio, LED walls, portable power distros
Technical Specifications
| Input Connector | NEMA 5-15P (Standard US 3-Prong) |
|---|---|
| Output Connector | Neutrik PowerCon NAC3FCA (Blue, Male) |
| Voltage Rating | 125V AC |
| Wire Gauge | 14AWG (2.08mm²) copper |
| Jacket Material | SJTOW (Oil/UV resistant) |
Why Choose PowerCon Over Standard Cables?
PowerCon NAC3FCA
- Locking mechanism prevents pull-outs
- IP54 rating when mated (dust/moisture resistant)
- 360° strain relief
- Standard in pro audio/lighting
Standard IEC
- Easily disconnects if tripped over
- No environmental sealing
- Weak strain relief
- Common in consumer gear
Frequently Asked Questions
Can I connect NAC3FCA to a PowerCon TRUE1?
No - NAC3FCA (blue) is the original PowerCon standard and is not compatible with TRUE1 (gray) connectors. They use different keying patterns to prevent accidental mating.
Is this cable suitable for outdoor use?
When properly mated, the NAC3FCA connection is IP54 rated. However, the NEMA 5-15P end is not waterproof. For permanent outdoor installations, we recommend
